Specifications

Supplier Name

 N/A AMI Bearings

Manufacturer Part Number

 N/A MBFPL6-20CB

Prop 65

 N/A Yes

Bolt Center-to-Center Length

 N/A 3.2500 in

Bore Diameter

 N/A 1.2500 in

Bore Type

 N/A Round

Duty Type

 N/A Standard Duty

End Type

 N/A Open Cover & Back Seal

Expansion Type

 N/A Non-Expansion Bearing (Fixed)

Housing Material

 N/A PBT Thermoplastic

Length Through Bore

 N/A 1.193 in

Locking Device

 N/A Set Screw

Lubrication Type

 N/A Relubricatable

Mounting Type

 N/A 4-Bolt Flange

Radial Dynamic Load Capacity

 N/A 3750 lbf

Radial Static Load Capacity

 N/A 2030 lbf

Replacement Bearing

 N/A MB6-20

Seal Type

 N/A Contact Seal

Series

 N/A MBFPL200CB
