Unit of Measure

Specifications

Supplier Name

 N/A AMI Bearings

Manufacturer Part Number

 N/A MBNFL4-12CW

Prop 65

 N/A Yes

Bolt Center-to-Center Length

 N/A 3.5469 in

Bore Diameter

 N/A 0.7500 in

Bore Type

 N/A Round

Duty Type

 N/A Standard Duty

End Type

 N/A Open Cover & Back Seal

Housing Material

 N/A PBT Thermoplastic

Length Through Bore

 N/A 0.866 in

Locking Device

 N/A Set Screw

Lubrication Type

 N/A Relubricatable

Mounting Type

 N/A 2-Bolt Flange

Overall Length/Diameter

 N/A 4.4375 in

Radial Dynamic Load Capacity

 N/A 2150 lbf

Radial Static Load Capacity

 N/A 1080 lbf

Replacement Bearing

 N/A MB4-12

Seal Type

 N/A Contact Seal

Series

 N/A MBNFL200CW

Features & Benefits

Features & Benefits

 N/A
  • 440C stainless steel insert is set screw locking with narrow inner ring
  • Housing is made of PBT thermoplastic with a thermoplastic open cover and spring loaded back seal
