Specifications

Supplier Name

 N/A AMI Bearings

Manufacturer Part Number

 N/A UKF209+HS2309

Prop 65

 N/A Yes

Bolt Center-to-Center Length

 N/A 4.1250 in

Bore Diameter

 N/A 1.6250 in

Bore Type

 N/A Round

Duty Type

 N/A Standard Duty

Expansion Type

 N/A Non-Expansion Bearing (Fixed)

Housing Material

 N/A Cast Iron

Length Through Bore

 N/A 1.969 in

Locking Device

 N/A Adapter Mount

Lubrication Type

 N/A Relubricatable

Mounting Type

 N/A 4-Bolt Flange

Radial Dynamic Load Capacity

 N/A 7420 lbf

Radial Static Load Capacity

 N/A 4610 lbf

Replacement Bearing

 N/A UK209+HS2309

Seal Type

 N/A Contact with Flinger

Series

 N/A UKF200+HS2000
