Unit of Measure

Specifications

Supplier Name

 N/A AMI Bearings

Manufacturer Part Number

 N/A UCFA211-35

Prop 65

 N/A Yes

Bolt Center-to-Center Length

 N/A 7.2500 in

Bore Diameter

 N/A 2.1875 in

Bore Type

 N/A Round

Duty Type

 N/A Standard Duty

Housing Material

 N/A Cast Iron

Length Through Bore

 N/A 0.866 in

Locking Device

 N/A Set Screw

Lubrication Type

 N/A Relubricatable

Mounting Type

 N/A 2-Bolt Flange

Overall Length/Diameter

 N/A 8.6250 in

Radial Dynamic Load Capacity

 N/A 2150 lbf

Radial Static Load Capacity

 N/A 1080 lbf

Replacement Bearing

 N/A UC211-35

Seal Type

 N/A Contact with Flinger

Series

 N/A UCFA200
