Item # 03773386, AMI 3.2500 Inch (in) Bore Diameter Flange-Mount Ball Bearing Unit On Motion Industries, Inc.

Unit of Measure

Supplier Name	N/A AMI Bearings
Manufacturer Part Number	N/A UCFCSX17-52
Prop 65	N/A Yes
Bolt Circle Diameter	N/A 8.6250 in
Bolt Size	N/A 0.7500 in
Bore Diameter	N/A 3.2500 in
Bore Type	N/A Round
Duty Type	N/A Medium Duty
Housing Material	N/A Cast Iron
Length Through Bore	N/A 3.780 in
Locking Device	N/A Set Screw
Lubrication Type	N/A Relubricatable
Mounting Type	N/A 4-Bolt Piloted
Overall Length/Diameter	N/A 10.2500 in
Pilot Diameter	N/A 7.375 in
Radial Dynamic Load Capacity	N/A 21500 lbf
Radial Static Load Capacity	N/A 16100 lbf
Replacement Bearing	N/A UCX17-52
Seal Type	N/A Contact with Flinger
Series	N/A UCFCSX00
Unit Standoff	N/A 2.610 in
