QJ344-N2-MPA Bearing
Unit of Measure

Specifications

Supplier Name

 N/A FAG (Schaeffler)

Manufacturer Part Number

 N/A QJ344-N2-MPA

Cage Material

 N/A Brass

Closure Type

 N/A Open

Fillet Radius

 N/A 4 mm

Finish/Coating

 N/A Uncoated

Inside Diameter

 N/A 220 mm

Internal Clearance

 N/A C0

Maximum Speed

 N/A 2430 rpm

Operating Temperature Range

 N/A -30 to 150 ºC

Outer Ring Width

 N/A 88 mm

Outside Diameter

 N/A 460 mm

Overall Width

 N/A 88 mm

Precision Rating

 N/A Not Rated

Radial Dynamic Load Capacity

 N/A 900000 N

Radial Static Load Capacity

 N/A 165000 N

Resistance Features

 N/A Chemical Resistant

Series

 N/A QJ3

Standards Met

 N/A DIN628-4
