Specifications

Supplier Name

 N/A AMI Bearings

Manufacturer Part Number

 N/A UCECH204NPMZ2

Prop 65

 N/A Yes

Bearing Material

 N/A AISI 52100 Steel - Zinc Protection

Bore Diameter

 N/A 20 mm

Hanger Unit Type

 N/A Conveyor Hanger Units

Housing Material

 N/A Cast Iron - Nickel Protection

Locking Device

 N/A Set Screw Collar

Outside Diameter

 N/A 70 mm

Radial Dynamic Load Capacity

 N/A 1310 kgf

Radial Static Load Capacity

 N/A 680 kgf

Replacement Bearing

 N/A UC204MZ2

Seal Type

 N/A Contact with Slinger

Series

 N/A UCECH200NPMZ2

Thread Length

 N/A 19 mm

Thread Size

 N/A PF3/4
