Item # 05330475, SMC® 1/2 Inch (in) Port Size Standard Air Regulator On Motion Industries, Inc.

Unit of Measure

Supplier Name	N/A SMC®
Manufacturer Part Number	N/A SRH4010-04
Fluid Compatibility	N/A Air Argon Carbon Dioxide (CO₂) Nitrogen Water
Maximum Operating Pressure	N/A 145 psi
Maximum Set Pressure	N/A 101 psi
Minimum Set Pressure	N/A 7.3 psi
Operating Temperature Range	N/A 32 to 140 ºF
Overall Height	N/A 58 mm
Overall Length	N/A 104.5 mm
Overall Width	N/A 52 mm
Port Gender	N/A Female
Port Size	N/A 1/2 in
Port Thread Standard	N/A British Standard Pipe Taper (BSPT)
Pressure Control Type	N/A Non-Relief Valve
