Specifications

Supplier Name

 N/A AMI Bearings

Manufacturer Part Number

 N/A UCPA206

Prop 65

 N/A Yes

Base to Bore Centerline

 N/A 1.6890 in

Base Width

 N/A 48 mm

Bolt Center-to-Center Length

 N/A 66 mm

Bolt Size

 N/A M14

Bore Diameter

 N/A 30 mm

Bore Type

 N/A Round

Duty Type

 N/A Standard Duty

Housing Material

 N/A Cast Iron

Locking Device

 N/A Set Screw

Lubrication Type

 N/A Lubrication Fitting

Mounting Type

 N/A Tapped Base

Overall Height

 N/A 84 mm

Overall Length

 N/A 94 mm

Overall Width

 N/A 48 mm

Radial Dynamic Load Capacity

 N/A 2000 kgf

Radial Static Load Capacity

 N/A 1150 kgf

Replacement Bearing

 N/A UC206

Seal Type

 N/A Contact with Slinger

Series

 N/A UCPA200
