Supplier Name |
N/A Nexen |
Manufacturer Part Number |
N/A 964408 |
Approximate Clutch Facing Life |
N/A 1050 hp·hr |
Bore Size |
N/A 1.3750 in |
Bore Type |
N/A Straight |
Clutch Air Chamber Volume when New |
N/A 3.109 in³ |
Clutch Air Chamber Volume when Worn Out |
N/A 4.657 in³ |
Clutch Category |
N/A Single Plate Clutch |
Clutch Facing Edge Color Code |
N/A Red |
Clutch Facing Type |
N/A Standard Coefficient |
Clutch Type |
N/A Friction Clutch |
Cv Factor |
N/A 0.120 |
Design |
N/A Enclosed |
Drive Inertia |
N/A 61.60 lb·in² |
Engagement |
N/A Air Engaged |
Release |
N/A Spring Release |
Finish |
N/A Black Oxide |
Input Shaft Diameter |
N/A 28 mm |
UPC Code |
N/A 662284236898 |
Maximum Speed |
N/A 1800 rpm |
Maximum Clutch Continuous Thermal Dissipation |
N/A 0.44 hp |
Maximum Pressure |
N/A 80 psi |
Maximum Static Clutch Torque |
N/A 1050 in·lb |
Minimum Engagement Pressure |
N/A 5 psi |
Mounting Configuration |
N/A Flange/Foot Mounted |
Number of Engagement Positions |
N/A Unlimited |
Output Shaft Diameter |
N/A 1.125 in |
Overhung Load Capacity |
N/A 350 lb |
Port Size |
N/A 1/8 in |
Port Type |
N/A National Pipe Thread (NPT) |
Rating |
N/A European Conformity (CE) Restriction of Hazardous Substances (RoHS) |
Shaft Inertia |
N/A 70.00 lb/in² |
Temperature Range |
N/A 32 to 150 ºF |
Weight |
N/A 68.00 lb |
