Supplier Name |
N/A Nexen |
Manufacturer Part Number |
N/A 961200 |
Model Number |
N/A DPC-11T |
Approximate Clutch Facing Life |
N/A 6300 hp·hr |
Bore Size |
N/A 0.5000 to 2.8750 in |
Bore Type |
N/A Quick-Detach (QD) Bushed |
Bushing Details |
N/A Accepts Quick Disconnect SF-style bushings ranging from 0.500 to 2.875 in. (Sold Separately). |
Bushing Series |
N/A SF |
Clutch Air Chamber Volume when New |
N/A 2.803 in³ |
Clutch Air Chamber Volume when Worn Out |
N/A 12.288 in³ |
Clutch Category |
N/A Dual Plate Clutch |
Clutch Facing Edge Color Code |
N/A Red |
Clutch Facing Effective Area |
N/A 93.00 in² |
Clutch Facing Type |
N/A Standard Coefficient |
Clutch Heat Sink Capacity |
N/A 360000 ft·lb |
Clutch Peak Thermal Input Rate |
N/A 84.00 hp |
Clutch Response Factor |
N/A 0.500 |
Clutch Type |
N/A Friction Clutch |
Design |
N/A Open |
Drive Arrangement |
N/A Pilot Mount |
Drive Inertia |
N/A 1022.40 lb·in² |
Engagement |
N/A Air Engaged |
Release |
N/A Spring Release |
Finish |
N/A Black Oxide |
Function |
N/A Starting, Connect/Disconnect, Torque Limiting |
Harmonization Code |
N/A 8483.60.4000 |
Maximum Speed |
N/A 1800 rpm |
Maximum Continuous Thermal Dissipation |
N/A 5.50 hp |
Maximum Pressure |
N/A 80 psi |
Minimum Engagement Pressure |
N/A 5 psi |
Minimum Sprocket Size |
N/A 100/21T 120/19T 60/33T 80/25T |
Mounting Configuration |
N/A Shaft Mounted |
Overall Diameter |
N/A 13.25 in |
Overall Length |
N/A 11.12 in |
Port Size |
N/A 1/4 in |
Port Type |
N/A National Pipe Thread (NPT) |
Rating |
N/A European Conformity (CE) Restriction of Hazardous Substances (RoHS) |
Shaft Inertia |
N/A 907.20 lb/in² |
Weight |
N/A 112.00 lb |
General Information |
N/A Torque at 80 psi: (DPC-9T) 5500 lb·in., (DPC-11T) 11,000 lb·in., (DPC-13T) 18,000 lb·in., (DPC-15T) 36,000 lb·in. Maximum operation speed: (DPC-9T) 2200 rpm, (DPC-11T) 1800 rpm, (DPC-13T) 1200 rpm, (DPC-15T) 900 rpm. Transmitted horsepower from 5.0-150. For through shaft mounting consult user manual for shaft drilling instructions. Not designed for vertical applications. Pilot mount clutches accept customer supplied pulleys, sprockets, or Nexen couplings. Sheaves are sold separately. |
