Supplier Name |
N/A US Motors (Nidec) |
Manufacturer Part Number |
N/A 8P32P1CCR |
Base Speed |
N/A 3505 rpm |
Duty/Condition Type |
N/A Continuous Duty |
Enclosure Type |
N/A Totally Enclosed Fan Cooled (TEFC) |
Frame Material |
N/A Cast Iron |
Frame Size |
N/A 143TC |
Frequency |
N/A 60 Hz |
Harmonization Code |
N/A 8501.52.4000 |
Type |
N/A IEEE 841 Motor |
Power for 2 Poles |
N/A 1-1/2 hp |
Phase |
N/A 3 |
Number of Poles |
N/A 2 |
Supply Voltage |
N/A 460 V |
Mounting Type |
N/A C-Face Flange Footless |
National Electrical Manufacturers Association (NEMA) Design Class |
N/A B |
Synchronous Speed |
N/A 3600 rpm |
Weight |
N/A 65.00 lb |
