Supplier Name |
N/A US Motors (Nidec) |
Manufacturer Part Number |
N/A U3P2DCR |
Base Speed |
N/A 1445 rpm1765 rpm |
Duty/Condition Type |
N/A Continuous Duty |
Enclosure Type |
N/A Totally Enclosed Fan Cooled (TEFC) |
Frame Material |
N/A Aluminum |
Frame Size |
N/A 182TC |
Frequency |
N/A 50 Hz60 Hz |
Full Load Current |
N/A 3.90 A8.40 to 7.80 A |
Full Load Efficiency |
N/A 89.50 % |
Harmonization Code |
N/A 8501.52.4000 |
Includes |
N/A Drip Cover |
Insulation Class |
N/A F |
Power for 4 Poles |
N/A 3 hp |
Phase |
N/A 3 |
Number of Poles |
N/A 4 |
Supply Voltage |
N/A 208 to 230 V460 V |
Mounting Type |
N/A C-Face Flange Footless |
National Electrical Manufacturers Association (NEMA) Design Class |
N/A B |
Shaft Diameter |
N/A 1.13 in |
Standards Met |
N/A European Conformity (CE) National Electrical Manufacturers Association (NEMA) |
Synchronous Speed |
N/A 1800 rpm |
Weight |
N/A 60 lb |
