DS80A18 Sprocket
Unit of Measure

Specifications

Supplier Name

 N/A Tsubaki (UST)

Manufacturer Part Number

 N/A DS80A18

Bore Diameter

 N/A 1.0000 in

Bore Type

 N/A Rough Stock

Chain Number

 N/A 80

Chain Pitch Size

 N/A 1 in

Hardened Teeth

 N/A Non-Hardened Teeth

Hub Diameter

 N/A 4-49/64 in

Length Through Bore

 N/A 2-3/16 in

Material

 N/A Steel

Maximum Bore Diameter

 N/A 3-1/8 in

Number of Hubs

 N/A 0

Number of Strands Across

 N/A 2

Number of Teeth

 N/A 18

Outside Diameter

 N/A 6.2700 in

Pitch Diameter

 N/A 5.759 in

Pitch Type

 N/A Single

Tooth Width

 N/A 0.557 in

Weight

 N/A 12.100 lb

Width Across Tooth Sets

 N/A 1.153 in
