Supplier Name |
N/A RBC® Bearings |
Manufacturer Part Number |
N/A JB042CP0-RBC |
UPC Code |
N/A 637400635251 |
Series |
N/A JB |
Prop 65 |
N/A Yes |
Bore Type |
N/A Round |
Dynamic Load Capacity |
N/A 1030 lbf |
ECCN |
N/A 2A001 |
Harmonization Code |
N/A 8482.10.5032 |
Axial Static Load Capacity |
N/A 1830 lbf |
Bearing Material |
N/A 52100 Bearing Quality Steel |
Bearing Type |
N/A Radial Contact |
Bore Diameter |
N/A 4.25 in |
Cage Material |
N/A Brass/Non-Metallic |
Closure Type |
N/A Sealed (Molded) |
Fillet Radius |
N/A 0.032 in |
Finish/Coating |
N/A Uncoated |
Inner Ring Width |
N/A 0.3125 in |
Internal Clearance |
N/A C0 |
Maximum Speed |
N/A 4380 rpm |
Operating Temperature Range |
N/A -60 to 250 ºF |
Outer Ring Width |
N/A 0.3125 in |
Outside Diameter |
N/A 4.88 in |
Outside Ring Shape |
N/A Straight |
Overall Width |
N/A 0.3125 in |
Radial Dynamic Load Capacity |
N/A 1030 lbf |
Radial Static Load Capacity |
N/A 1830 lbf |
Standards Met |
N/A American Iron and Steel Institute (AISI 52100) |
Operating Temperature [Max] |
N/A 250 ºF |
Number of Rows |
N/A 1 |
Fill Slot |
N/A Non-Fill Slot |
Snap Ring Included |
N/A Without Snap Ring |
Static Load Capacity |
N/A 1830 lbf |
Weight |
N/A 0.310 lb |
