MB34 Adapter/Withdrawal Sleeve
Unit of Measure

Specifications

Supplier Name

 N/A FAG (Schaeffler)

Manufacturer Part Number

 N/A MB34

Bore Diameter

 N/A 170 mm

Compatible Lock Nut Number

 N/A KM34

Face Diameter

 N/A 193 mm

Key Width

 N/A 18 mm

UPC Code

 N/A 4012801224581

Material

 N/A Steel

Outside Diameter Over Tangs

 N/A 232 mm

Series

 N/A MB

Tang Thickness

 N/A 2.5 mm

Tang Width

 N/A 16 mm
