Supplier Name |
N/A US Motors (Nidec) |
Manufacturer Part Number |
N/A D7C1K |
Base Speed |
N/A 3490 rpm |
Duty/Condition Type |
N/A Continuous Duty |
Enclosure Type |
N/A Open Drip-Proof (ODP) |
Frame Material |
N/A Steel |
Frame Size |
N/A 184T |
Frequency |
N/A 60 Hz |
Full Load Current |
N/A 30.00 A |
Harmonization Code |
N/A 8501.40.6040 |
Insulation Class |
N/A F |
Type |
N/A Compressor Duty Motor |
Power for 2 Poles |
N/A 7-1/2 hp |
Phase |
N/A 1 |
Number of Poles |
N/A 2 |
Supply Voltage |
N/A 230 V |
Mounting Type |
N/A Footed Horizontal |
Shaft Diameter |
N/A 1.13 in |
Standards Met |
N/A National Electrical Manufacturers Association (NEMA) |
Synchronous Speed |
N/A 3600 rpm |
Thermal Protection |
N/A Manual |
Weight |
N/A 80.00 lb |
