2306-2RS-TVH Bearing
Unit of Measure

Specifications

Supplier Name

 N/A FAG (Schaeffler)

Manufacturer Part Number

 N/A 2306-2RS-TVH

Bore Diameter

 N/A 30 mm

Bore Type

 N/A Straight

Cage Material

 N/A Polyamide

Closure Type

 N/A Double Sealed

Dynamic Load Rating

 N/A 21700 N

Fillet Radius

 N/A 1 mm

Finish/Coating

 N/A Uncoated

Internal Clearance

 N/A C0

Maximum Misalignment

 N/A 1.5 º

Maximum Speed

 N/A 6700 rpm

Operating Temperature Range

 N/A -30 to 100 ºC

Outer Ring Width

 N/A 27 mm

Outside Diameter

 N/A 72 mm

Overall Width

 N/A 27 mm

Precision Rating

 N/A Annular Bearings Engineers Committee (ABEC) 1 (International Organization for Standardization (ISO) Class Normal) P0

Series

 N/A 23

Standards Met

 N/A DIN 630

Static Load Rating

 N/A 6300 N

Weight

 N/A 1.1 lb
