PCCJ35 Four-Bolt Flanged Unit
Unit of Measure

Specifications

Supplier Name

 N/A INA (Schaeffler)

Manufacturer Part Number

 N/A PCCJ35

Bolt Center-to-Center Length

 N/A 92 mm

Bore Diameter

 N/A 35 mm

Bore Type

 N/A Round

Expansion Type

 N/A Non-Expansion Bearing (Fixed)

Finish/Coating

 N/A Uncoated

Housing Material

 N/A Cast Iron

Lubrication Type

 N/A Relubricatable

Mounting Type

 N/A 4-Bolt Flange

Overall Length/Diameter

 N/A 118 mm

Radial Dynamic Load Capacity

 N/A 39500 N

Radial Static Load Capacity

 N/A 29000 N

Replacement Bearing

 N/A G5207-2RS-N

Seal Type

 N/A Double Lip

Series

 N/A PCCJ

Weight

 N/A 3.91 lb
