Specifications

Supplier Name

 N/A AMI Bearings

Manufacturer Part Number

 N/A KHR208

Prop 65

 N/A Yes

Bearing Material

 N/A AISI 52100 Steel

Bore Diameter

 N/A 40 mm

Bore Type

 N/A Round

Inner Ring Width

 N/A 43.7 mm

Locking Device

 N/A Eccentric Collar

Outer Ring Width

 N/A 18 mm

Outside Diameter

 N/A 3.1496 in

Radial Dynamic Load Capacity

 N/A 2990 kgf

Radial Static Load Capacity

 N/A 1830 kgf

Seal Type

 N/A Contact Seal

Series

 N/A KHR200
