Supplier Name |
N/A US Motors (Nidec) |
Manufacturer Part Number |
N/A X150P2C |
Base Speed |
N/A 1785 rpm |
Duty/Condition Type |
N/A Hazardous Location |
Enclosure Type |
N/A Totally Enclosed Fan Cooled (TEFC) |
Frame Material |
N/A Cast Iron |
Frame Size |
N/A 445T |
Frequency |
N/A 60 Hz |
Full Load Current |
N/A 171.00 A |
Full Load Efficiency |
N/A 95.80 % |
Group and Class |
N/A Class I - Group D Class II - Group F & G |
Harmonization Code |
N/A 8501.53.4080 |
Includes |
N/A Cast Iron Fan Cover |
Insulation Class |
N/A F |
Ingress Protection Rating |
N/A Ingress Protection (IP54) |
Type |
N/A General Purpose Motor |
Power for 4 Poles |
N/A 150 hp |
Phase |
N/A 3 |
Number of Poles |
N/A 4 |
Supply Voltage |
N/A 460 V |
Mounting Type |
N/A Footed Horizontal |
National Electrical Manufacturers Association (NEMA) Design Class |
N/A B |
Shaft Diameter |
N/A 3.38 in |
Standards Met |
N/A Canadian Standards Association (CSA) National Electrical Manufacturers Association (NEMA) Underwriter Laboratories (UL) |
Synchronous Speed |
N/A 1800 rpm |
Temperature Code |
N/A T3B |
Weight |
N/A 1625.00 lb |
