Supplier Name |
N/A Nexen |
Manufacturer Part Number |
N/A 928500 |
Model Number |
N/A MBU-625 |
Approximate Brake Facing Life |
N/A 394 hp·hr |
Bore Size |
N/A 5/8 in |
Bore Type |
N/A Straight |
Brake Air Chamber Volume when New |
N/A 0.550 in³ |
Brake Air Chamber Volume when Worn Out |
N/A 1.392 in³ |
Brake Facing Edge Color Code |
N/A Red |
Brake Facing Effective Area |
N/A 12.8 in² |
Brake Facing Type |
N/A Standard Coefficient |
Brake Heat Sink Capacity |
N/A 45000 ft·lb |
Brake Peak Thermal Input Rate |
N/A 12.00 hp |
Brake Response Factor |
N/A 0.096 |
Brake Series |
N/A MBU |
Engagement |
N/A Air Engaged |
Release |
N/A Spring Release |
Facing Kit |
N/A 930276 |
Finish |
N/A Black Oxide |
Frame Size |
N/A 56C |
Frame Type |
N/A National Electrical Manufacturers Association (NEMA) |
Function |
N/A Stopping, Holding, and Tensioning |
Guards |
N/A 929502 |
Input Shaft Diameter |
N/A 0.625 in |
Maximum Speed |
N/A 1800 rpm |
Maximum Brake Continuous Thermal Dissipation |
N/A 0.23 hp |
Maximum Pressure |
N/A 80 psi |
Maximum Static Brake Torque |
N/A 540 in·lb |
Minimum Engagement Pressure |
N/A 5 psi |
Mounting Configuration |
N/A Flange Mounted |
Open or Enclosed Design |
N/A Open |
Output Shaft Diameter |
N/A 0.625 in |
Overhung Load Capacity |
N/A 281 lb |
Port Size |
N/A 1/8 in |
Port Type |
N/A National Pipe Thread (NPT) |
Rating |
N/A European Conformity (CE) Restriction of Hazardous Substances (RoHS) |
Rebuild Kits |
N/A 930200 |
Recommended Control Kits |
N/A 940011 (3-Way Normally Open (N.O.) 1/8 in. National Pipe Thread (NPT)) 940012 (3-Way Normally Closed (N.C.) 1/8 in. National Pipe Thread (NPT)) 940017 (3-Way Normally Closed (N.C.) 0 to 100 PSI 1/8 in. National Pipe Thread (NPT)) 940021 (3-Way 5 to 100 psi 1/8 in. National Pipe Thread (NPT)) |
Shaft Inertia |
N/A 9.06 lb/in² |
Weight |
N/A 16 lb |
