Supplier Name |
N/A Nexen |
Manufacturer Part Number |
N/A 827380 |
Model Number |
N/A FMBES-1375 |
Approximate Brake Facing Life |
N/A 571 hp·hr |
Approximate Engagement Response Time |
N/A 30 ms |
Bore Size |
N/A 1.3750 in |
Bore Type |
N/A Straight |
Brake Air Chamber Volume when New |
N/A 78.400 in³ |
Brake Air Chamber Volume when Worn Out |
N/A 16.200 in³ |
Brake Facing Edge Color Code |
N/A Red |
Brake Facing Effective Area |
N/A 31.9 in² |
Brake Facing Type |
N/A Standard Coefficient |
Brake Series |
N/A FMBES |
Engagement |
N/A Spring Engaged |
Release |
N/A Air Release |
Facing Kit |
N/A 827304 |
Finish |
N/A Nickel Plated |
Frame Size |
N/A 213TC 215TC |
Frame Type |
N/A National Electrical Manufacturers Association (NEMA) |
Function |
N/A Stopping and Holding |
Maximum Speed |
N/A 1800 rpm |
Maximum Brake Continuous Thermal Dissipation |
N/A 0.44 hp |
Maximum Pressure |
N/A 80 psi |
Minimum Release Pressure |
N/A 60 psi |
Minimum Static Brake Torque |
N/A 900 in·lb |
Mounting Configuration |
N/A Flange Mounted |
Open or Enclosed Design |
N/A Enclosed |
Overhung Load Capacity |
N/A 290 lb |
Port Size |
N/A 1/8 in |
Port Type |
N/A National Pipe Thread (NPT) |
Rating |
N/A European Conformity (CE) Ingress Protection (IP54) National Electrical Manufacturers Association (NEMA) 1.26.55 (Waterproof Machines) Restriction of Hazardous Substances (RoHS) |
Rebuild Kits |
N/A 827303 |
Recommended Control Kits |
N/A 940012 (3-Way Normally Closed (N.C.) 1/8 in. National Pipe Thread (NPT)) 940017 (3-Way Normally Closed (N.C.) 0 to 100 PSI 1/8 in. National Pipe Thread (NPT)) 940021 (3-Way 5 to 100 psi 1/8 in. National Pipe Thread (NPT)) |
Shaft Inertia |
N/A 12960.00 lb/in² |
Weight |
N/A 56.00 lb |
