Supplier Name |
N/A Nexen |
Manufacturer Part Number |
N/A 962000 |
Model Number |
N/A DPB-13T |
Approximate Brake Facing Life |
N/A 9827 hp·hr |
Bore Size |
N/A 1 in1.0000 to 3.5000 in1.1250 in1.1875 in1.3125 in1.3750 in1.4375 in1.5625 in1.6250 in1.6875 in1.7500 in1.8125 in1.8750 in1.9375 in1-1/2 in1-1/4 in2 in2.0625 in2.1250 in2.1875 in2.2500 in2.3125 in2.3750 in2.4375 in2.5625 in2.6250 in2.6875 in2.7500 in2.8125 in2.8750 in2.9375 in2-1/2 in3.0000 in3.1250 in3.1875 in3.2500 in3.3125 in3.3750 in3.4375 in3.5000 in |
Bore Style |
N/A F Bushing (1.000 to 3.500 in.) |
Bore Type |
N/A Quick-Detach (QD) Bushed |
Brake Air Chamber Volume when New |
N/A 7.326 in³ |
Brake Air Chamber Volume when Worn Out |
N/A 35.525 in³ |
Brake Facing Edge Color Code |
N/A Red |
Brake Facing Effective Area |
N/A 144.5 in² |
Brake Facing Type |
N/A Standard Coefficient |
Brake Heat Sink Capacity |
N/A 690000 ft·lb |
Brake Peak Thermal Input Rate |
N/A 130.00 hp |
Brake Response Factor |
N/A 0.702 |
Bushing Type |
N/A F Type |
Bushing Range |
N/A 1.0000 to 3.5000 in |
Engagement |
N/A Air Engaged |
Release |
N/A Spring Release |
Finish |
N/A Black Oxide |
Function |
N/A Stopping and Holding |
Maximum Speed |
N/A 1200 rpm |
Maximum Brake Continuous Thermal Dissipation |
N/A 8.00 hp |
Maximum Pressure |
N/A 80 psi |
Maximum Static Brake Torque |
N/A 18000 in·lb |
Open or Enclosed Design |
N/A Open |
Other Accessories |
N/A 962100 (Torque Arm) |
Overall Diameter |
N/A 15.75 in |
Overall Length |
N/A 6.80 in |
Port Size |
N/A 1/8 in |
Port Type |
N/A National Pipe Thread (NPT) |
Rating |
N/A European Conformity (CE) Restriction of Hazardous Substances (RoHS) |
Shaft Inertia |
N/A 2694.00 lb/in² |
Weight |
N/A 200.00 lb |
