Supplier Name |
N/A Nexen |
Manufacturer Part Number |
N/A 824305 |
Model Number |
N/A T-1000A |
Approximate Brake Facing Life |
N/A 3066 hp·hr |
Bore Size |
N/A 0.8750 in0.8750 to 2.8750 in0.9375 in1 in1.1250 in1.1875 in1.3125 in1.3750 in1.4375 in1.5625 in1.6250 in1.6875 in1.7500 in1.8125 in1.8750 in1.9375 in1-1/2 in1-1/4 in2 in2.0625 in2.1250 in2.1875 in2.2500 in2.3125 in2.3750 in2.4375 in2.5625 in2.6250 in2.6875 in2.7500 in2.8125 in2.8750 in2-1/2 in |
Bore Style |
N/A E Bushing (0.8750 to 2.8750 in.) |
Bore Type |
N/A Quick-Detach (QD) Bushed |
Brake Air Chamber Volume when New |
N/A 4.222 in³ |
Brake Air Chamber Volume when Worn Out |
N/A 10.443 in³ |
Brake Facing Edge Color Code |
N/A Red |
Brake Facing Effective Area |
N/A 50.3 in² |
Brake Facing Type |
N/A Standard Coefficient |
Brake Heat Sink Capacity |
N/A 391048 ft·lb |
Brake Peak Thermal Input Rate |
N/A 45.00 hp |
Brake Response Factor |
N/A 0.398 |
Brake Series |
N/A T-1000A |
Bushing Type |
N/A E Type |
Bushing Range |
N/A 0.8750 to 2.8750 in |
Engagement |
N/A Air Engaged |
Release |
N/A Spring Release |
Facing Kit |
N/A 827571 |
Finish |
N/A Black Oxide |
Function |
N/A Tensioning |
Guards |
N/A 828200 |
Maximum Speed |
N/A 1800 rpm |
Maximum Brake Continuous Thermal Dissipation |
N/A 5.54 hp |
Maximum Dynamic Torque Capacity |
N/A 2933 in·lb |
Maximum Pressure |
N/A 80 psi |
Minimum Engagement Pressure |
N/A 3 psi |
Mounting Configuration |
N/A Shaft Mounted |
Open or Enclosed Design |
N/A Open |
Overall Diameter |
N/A 11.88 in |
Overall Length |
N/A 4.40 in |
Port Size |
N/A 1/4 in |
Port Type |
N/A National Pipe Thread (NPT) |
Rating |
N/A European Conformity (CE) Restriction of Hazardous Substances (RoHS) |
Rebuild Kits |
N/A 827502 |
Shaft Inertia |
N/A 183.19 lb/in² |
Torque Pin Bracket |
N/A 825500 |
