Supplier Name |
N/A US Motors (Nidec) |
Manufacturer Part Number |
N/A DJ3C2P18M |
Base Speed |
N/A 1735 rpm |
Duty/Condition Type |
N/A Continuous Duty |
Enclosure Type |
N/A Open Drip-Proof (ODP) |
Frame Material |
N/A Steel |
Frame Size |
N/A 184JM |
Frequency |
N/A 60 Hz |
Harmonization Code |
N/A 8501.40.6040 |
Type |
N/A Close Coupled Pump Motor |
Power for 4 Poles |
N/A 3 hp |
Phase |
N/A 1 |
Number of Poles |
N/A 4 |
Supply Voltage |
N/A 115 V230 V |
Mounting Type |
N/A Footed Horizontal |
National Electrical Manufacturers Association (NEMA) Design Class |
N/A L |
Synchronous Speed |
N/A 1800 rpm |
Weight |
N/A 66.00 lb |
