Supplier Name |
N/A US Motors (Nidec) |
Manufacturer Part Number |
N/A FF125E1CS |
Base Speed |
N/A 2965 rpm3565 rpm |
Duty/Condition Type |
N/A Continuous Duty |
Enclosure Type |
N/A Open Drip-Proof (ODP) |
Frame Material |
N/A Cast Iron |
Frame Size |
N/A 404TS |
Frequency |
N/A 50 Hz60 Hz |
Full Load Current |
N/A 137.00 A |
Full Load Efficiency |
N/A 94.10 % |
Harmonization Code |
N/A 8501.53.4080 |
Insulation Class |
N/A F |
Type |
N/A Fire Pump Motor |
Power for 2 Poles |
N/A 100 hp125 hp |
Phase |
N/A 3 |
Number of Poles |
N/A 2 |
Supply Voltage |
N/A 460 V |
Mounting Type |
N/A Footed Horizontal |
National Electrical Manufacturers Association (NEMA) Design Class |
N/A B |
Shaft Diameter |
N/A 2.13 in |
Standards Met |
N/A European Conformity (CE) National Electrical Manufacturers Association (NEMA) |
Synchronous Speed |
N/A 3600 rpm |
Weight |
N/A 750.00 lb |
