50 1780 HT50P2BLG 230/460 60 326TP
Unit of Measure

Specifications

Supplier Name

 N/A US Motors (Nidec)

Manufacturer Part Number

 N/A HT50P2BLG

Base Speed

 N/A 1780 rpm

Enclosure Type

 N/A TEFC (Totally Enclosed Fan Cooled)

Frame Size

 N/A 326TP

Insulation Class

 N/A F

Motor Power

 N/A 50 hp

Frequency Rating

 N/A 60 Hz

Motor Supply Voltage

 N/A 230 V460 V

Phase

 N/A 3

Number of Poles

 N/A 4

Mounting Type

 N/A Vertical

Service Factor

 N/A 1.15

Synchronous Speed

 N/A 1800 rpm

Weight

 N/A 690.00 lb

Applications

Applications

 N/A Mix Flow Propeller Pumps Turbine
