Unit of Measure

Specifications

Supplier Name

 N/A RBC® Bearings

Manufacturer Part Number

 N/A 5NCC1011P

UPC Code

 N/A 637400497491

Series

 N/A NCC

Prop 65

 N/A Yes

Bearing Material

 N/A 52100 Bearing Quality Steel

Bearing Type

 N/A Needle Roller

Bore Diameter

 N/A 0.31 in

Closure Type

 N/A Open

Dynamic Load Capacity

 N/A 988 lbf

Fillet Radius

 N/A 0.022 in

Finish/Coating

 N/A Cadmium

Flanges

 N/A No Flange

Lubrication Hole Type

 N/A Hole on Inner Ring

Maximum Speed

 N/A 100 rpm

Needle Bearing Type

 N/A Roller and Cage Assembly

Number of Rows

 N/A 1

Outside Diameter

 N/A 0.69 in

Overall Width

 N/A 0.625 in

Precision Rating

 N/A Not Rated

Standards Met

 N/A Anti-Friction Bearing Manufacturers Association (AFBMA) Military (MIL)

Static Load Capacity

 N/A 988 lbf

Weight

 N/A 0.05 lb

Applications

Applications

 N/A Used in aerospace and industrial applications that necessitate the most stringent tolerances.
