LR206-X-2RS Yoke Type Track Roller
Unit of Measure

Specifications

Supplier Name

 N/A INA (Schaeffler)

Manufacturer Part Number

 N/A LR206-X-2RS

Bearing Element

 N/A Balls - One Row

Bore Diameter

 N/A 30 mm

Closure Type

 N/A Sealed

Finish/Coating

 N/A Uncoated

Lubrication Hole Location

 N/A Inner Ring

Maximum Speed

 N/A 7100 rpm

Operating Temperature Range

 N/A -20 to 120 ºC

Radial Dynamic Load Capacity

 N/A 3735 lbf

Radial Static Load Capacity

 N/A 2160 lbf

Roller Diameter

 N/A 72 mm

Roller Shape

 N/A Flat

Roller Width

 N/A 16 mm

Weight

 N/A 0.87 lb
