Unit of Measure

Specifications

Supplier Name

 N/A AMI Bearings

Manufacturer Part Number

 N/A BLLP2

Prop 65

 N/A Yes

Base to Bore Centerline

 N/A 1.1890 in

Base Width

 N/A 25 mm

Bolt Center-to-Center Length

 N/A 81 to 94 mm

Bolt Size

 N/A M10

Bore Diameter

 N/A 15 mm

Bore Type

 N/A Round

Duty Type

 N/A Standard Duty

Expansion Type

 N/A Non-Expansion Bearing (Fixed)

Housing Material

 N/A Cast Iron

Locking Device

 N/A Set Screw

Lubrication Type

 N/A Cannot Be Relubricated

Mounting Type

 N/A 2-Bolt Base

Overall Height

 N/A 57 mm

Overall Length

 N/A 114 mm

Overall Width

 N/A 28.5 mm

Radial Dynamic Load Capacity

 N/A 975 kgf

Radial Static Load Capacity

 N/A 490 kgf

Replacement Bearing

 N/A B2

Seal Type

 N/A Contact/Lip

Series

 N/A BLLP200
