Unit of Measure

Specifications

Supplier Name

 N/A AMI Bearings

Manufacturer Part Number

 N/A BSHE208

Prop 65

 N/A Yes

Base to Bore Centerline

 N/A 1.9370 in

Base Width

 N/A 48 mm

Bolt Center-to-Center Length

 N/A 88.9 mm

Bolt Size

 N/A M12

Bore Diameter

 N/A 40 mm

Bore Type

 N/A Round

Duty Type

 N/A Standard Duty

Housing Material

 N/A Cast Iron

Locking Device

 N/A Set Screw

Lubrication Type

 N/A Lubrication Fitting

Mounting Type

 N/A Tapped Base

Overall Height

 N/A 99 mm

Overall Length

 N/A 116 mm

Overall Width

 N/A 50.5 mm

Radial Dynamic Load Capacity

 N/A 2990 kgf

Radial Static Load Capacity

 N/A 1830 kgf

Replacement Bearing

 N/A B8

Seal Type

 N/A Contact/Lip

Series

 N/A BSHE200
