Climax Metal Two-Piece Recessed Screw Clamping Couplings with Keyway On Motion Industries, Inc.

COMPANY HEADER

CAD (0) ▾

Terms

1 - 25 of 30 | Results Per Page | View | Unit of Measure

1 2

Request Information Compare Items Add to CAD Cart

Item #	Item Name	Bore - Side 1	Outside Diameter	Overall Length	Screw Thread Size

02393050	N/A Climax Metal 2.0000 Inch (in) Outside Diameter Two-Piece Recessed Screw Clamping Coupling with Keyway	N/A 1.0000 in	N/A 2.0000 in	N/A 3.0000 in	N/A 1/4-28 x 5/8 in
02393051	N/A Climax Metal 1.5000 Inch (in) Outside Diameter Two-Piece Recessed Screw Clamping Coupling with Keyway	N/A 0.6250 in	N/A 1.50 in	N/A 2.2500 in	N/A 10-32 x 1/2 in
02393052	N/A Climax Metal 1.7500 Inch (in) Outside Diameter Two-Piece Recessed Screw Clamping Coupling with Keyway	N/A 0.7500 in	N/A 1.75 in	N/A 2.6250 in	N/A 1/4-28 x 5/8 in
02393053	N/A Climax Metal 2.1250 Inch (in) Outside Diameter Two-Piece Recessed Screw Clamping Coupling with Keyway	N/A 1.1250 in	N/A 2.1250 in	N/A 3.2500 in	N/A 1/4-28 x 3/4 in
02393054	N/A Climax Metal 1.8750 Inch (in) Outside Diameter Two-Piece Recessed Screw Clamping Coupling with Keyway	N/A 0.8750 in	N/A 1.8750 in	N/A 2.8750 in	N/A 1/4-28 x 5/8 in
02393055	N/A Climax Metal 2.0000 Inch (in) Outside Diameter Two-Piece Recessed Screw Clamping Coupling with Keyway	N/A 1.0000 in	N/A 2.0000 in	N/A 3.0000 in	N/A 1/4-28 x 5/8 in
02393056	N/A Climax Metal 2.3750 Inch (in) Outside Diameter Two-Piece Recessed Screw Clamping Coupling with Keyway	N/A 1.3750 in	N/A 2.3750 in	N/A 3.6250 in	N/A 1/4-28 x 3/4 in
02393057	N/A Climax Metal 3.2500 Inch (in) Outside Diameter Two-Piece Recessed Screw Clamping Coupling with Keyway	N/A 2.0000 in	N/A 3.25 in	N/A 4.8750 in	N/A 5/16-24 x 1 in
02415066	N/A Climax Metal 3.5000 Inch (in) Outside Diameter Two-Piece Recessed Screw Clamping Coupling with Keyway	N/A 2.2500 in	N/A 3.50 in	N/A 5 in	N/A 5/16-24 x 1 in
06707914	N/A Climax Metal 1.0625 Inch (in) Outside Diameter Two-Piece Recessed Screw Clamping Coupling with Keyway	N/A 0.3750 in	N/A 1.0625 in	N/A 1.6250 in	N/A 6-32 x 1/2 in
06707915	N/A Climax Metal 1.2500 Inch (in) Outside Diameter Two-Piece Recessed Screw Clamping Coupling with Keyway	N/A 0.5000 in	N/A 1.25 in	N/A 1.8750 in	N/A 8-32 x 1/2 in
06707916	N/A Climax Metal 1.7500 Inch (in) Outside Diameter Two-Piece Recessed Screw Clamping Coupling with Keyway	N/A 0.7500 in	N/A 1.75 in	N/A 2.6250 in	N/A 1/4-28 x 5/8 in
06707838	N/A Climax Metal 1.8750 Inch (in) Outside Diameter Two-Piece Recessed Screw Clamping Coupling with Keyway	N/A 0.8750 in	N/A 1.8750 in	N/A 2.6250 in	N/A 1/4-28 x 5/8 in
06707839	N/A Climax Metal 2.0000 Inch (in) Outside Diameter Two-Piece Recessed Screw Clamping Coupling with Keyway	N/A 1.0000 in	N/A 2.0000 in	N/A 3.0000 in	N/A 1/4-28 x 5/8 in
04815362	N/A Climax Metal 2.1250 Inch (in) Outside Diameter Two-Piece Recessed Screw Clamping Coupling with Keyway	N/A 1.1250 in	N/A 2.1250 in	N/A 3.2500 in	N/A 1/4-28 x 3/4 in
07028247	N/A Climax Metal 2.2500 Inch (in) Outside Diameter Two-Piece Recessed Screw Clamping Coupling with Keyway	N/A 1.2500 in	N/A 2.2500 in	N/A 3.3750 in	N/A 1/4-28 x 3/4 in
07028245	N/A Climax Metal 1.5000 Inch (in) Outside Diameter Two-Piece Recessed Screw Clamping Coupling with Keyway	N/A 0.8750 in	N/A 1.50 in	N/A 2.2500 in	N/A 10-32 x 1/2 in
07026880	N/A Climax Metal 1.2500 Inch (in) Outside Diameter Two-Piece Recessed Screw Clamping Coupling with Keyway	N/A 0.5000 in	N/A 1.25 in	N/A 1.8750 in	N/A 8-32 x 1/2 in
07026865	N/A Climax Metal 2.5000 Inch (in) Outside Diameter Two-Piece Recessed Screw Clamping Coupling with Keyway	N/A 1.5000 in	N/A 2.50 in	N/A 3-3/4 in	N/A 1/4-28 x 3/4 in
07026858	N/A Climax Metal 2.2500 Inch (in) Outside Diameter Two-Piece Recessed Screw Clamping Coupling with Keyway	N/A 1.2500 in	N/A 2.2500 in	N/A 3.3750 in	N/A 1/4-28 x 3/4 in
07026855	N/A Climax Metal 3.0000 Inch (in) Outside Diameter Two-Piece Recessed Screw Clamping Coupling with Keyway	N/A 1.7500 in	N/A 3.00 in	N/A 4-1/2 in	N/A 5/16-24 x 1 in
07026854	N/A Climax Metal 2.3750 Inch (in) Outside Diameter Two-Piece Recessed Screw Clamping Coupling with Keyway	N/A 1.3750 in	N/A 2.3750 in	N/A 3.6250 in	N/A 1/4-28 x 3/4 in
07026721	N/A Climax Metal 1.7500 Inch (in) Outside Diameter Two-Piece Recessed Screw Clamping Coupling with Keyway	N/A 0.7500 in	N/A 1.75 in	N/A 2.6250 in	N/A 1/4-28 x 5/8 in
07033818	N/A Climax Metal 2.5000 Inch (in) Outside Diameter Two-Piece Recessed Screw Clamping Coupling with Keyway	N/A 1.5000 in	N/A 2.50 in	N/A 3-3/4 in	N/A 1/4-28 x 3/4 in
08939483	N/A Climax Metal 3.6250 Inch (in) Outside Diameter Two-Piece Recessed Screw Clamping Coupling with Keyway	N/A 1.9375 in	N/A 3.6250 in	N/A 6 in	N/A 3/8-24

1 - 25 of 30 | Results Per Page | View | Unit of Measure

1 2
