Unit of Measure

Specifications

Brands

 N/A Fibriloid®

Supplier Name

 N/A RBC® Bearings

Manufacturer Part Number

 N/A 0382503

UPC Code

 N/A 637400371494

Prop 65

 N/A Yes

Axial Static Load Capacity

 N/A 150 lbf

Bearing Material

 N/A Stainless Steel

Bearing Type

 N/A Spherical

Bore Diameter

 N/A 0.19 in

Bore Type

 N/A Round

Closure Type

 N/A Open

Housing Material

 N/A CRES 17-4PH, AMS 5643, HRC 28 min.

Inner Ring Width

 N/A 0.281 in

Liner Material

 N/A Polytetrafluoroethylene (PTFE)

Lubrication Type

 N/A Self-Lubricating

Maximum PV Value Dry (psi x fpm)

 N/A 50000

Misalignment Angle

 N/A 10 º

Operating Temperature Range

 N/A -65 to 325 ºF

Outer Ring Material

 N/A CRES 17-4PH, AMS 5643, HRC 28 min.

Outer Ring Width

 N/A 0.218 in

Outside Diameter

 N/A 0.56 in

Overall Width

 N/A 0.2810 in

Race Material

 N/A Polytetrafluoroethylene (PTFE)

Radial Dynamic Load Capacity

 N/A 1500 lbf

Radial Static Load Capacity

 N/A 3975 lbf

Standards Met

 N/A Military Specification (MS14101) Military Specification (MS14126) Society of Automotive Engineers (SAE-AS81820)

Weight

 N/A 0.02 lb

Applications

Applications

 N/A Chain Conveyors Extractors Forklift Trucks Front End Loaders Haul Trucks Hydraulic Cranes Log Skidders Overhead Carriers Satellite Antennas Wind Turbines

Features & Benefits

Features & Benefits

 N/A
  • The outer ring is swaged over the ball to provide maximum race to ball conformity
  • Grooved outer race for staking the bearing in the housing
  • Swaged self-lubricating bearing allow for misalignment and high load carrying capacity
  • This bearing is not intended for use in any aerospace application
