Specifications

Brands

 N/A Pitchlign®

Supplier Name

 N/A RBC® Bearings

Manufacturer Part Number

 N/A SJ8447

Prop 65

 N/A Yes

Series

 N/A SJ

Bore Diameter

 N/A 2.5 in

Closure Type

 N/A Double Sealed

Dynamic Load Capacity

 N/A 18400 lbf

Flanges

 N/A No Flange

Lubrication Hole Type

 N/A Hole on Outer Ring

Maximum Speed

 N/A 5300 rpm

Needle Bearing Type

 N/A Machined Bearing with No Inner Ring

Number of Rows

 N/A 1

Operating Temperature Range

 N/A -40 to +300 ºF

Outside Diameter

 N/A 3.25 in

Overall Width

 N/A 1.7500 in

Precision Rating

 N/A Not Rated

Static Load Capacity

 N/A 44500 lb
