Supplier Name |
N/A Nexen |
Manufacturer Part Number |
N/A 808242 |
Model Number |
N/A SE-500 |
Approximate Brake Facing Life |
N/A 356 hp·hr |
Approximate Engagement Response Time |
N/A 30 ms |
Bore Size |
N/A 1.1250 in |
Bore Type |
N/A Straight |
Brake Air Chamber Volume when New |
N/A 78.400 in³ |
Brake Air Chamber Volume when Worn Out |
N/A 16.200 in³ |
Brake Facing Edge Color Code |
N/A Red |
Brake Facing Type |
N/A Standard Coefficient |
Brake Peak Thermal Input Rate |
N/A 34.00 hp |
Engagement |
N/A Spring Engaged |
Release |
N/A Air Release |
Finish |
N/A Black Oxide |
Frame Size |
N/A 182TC |
UPC Code |
N/A 662284194600 |
Maximum Speed |
N/A 1800 rpm |
Maximum Brake Continuous Thermal Dissipation |
N/A 0.20 hp |
Maximum Pressure |
N/A 80 psi |
Minimum Release Pressure |
N/A 30 psi |
Minimum Static Brake Torque |
N/A 240 in·lb |
Open or Enclosed Design |
N/A Enclosed |
Port Size |
N/A 1/8 in |
Port Type |
N/A National Pipe Thread (NPT) |
Rating |
N/A European Conformity (CE) Restriction of Hazardous Substances (RoHS) |
Shaft Inertia |
N/A 12960.00 lb/in² |
Weight |
N/A 30.00 lb |
