Supplier Name |
N/A Nexen |
Manufacturer Part Number |
N/A 801305 |
Model Number |
N/A MB-600 |
Accessory Hubs |
N/A 801331 (0.875 in. Bore), 801332 (1.000 in. Bore), 801333 (1.125 in. Bore), 801334 (1.250 in. Bore), 801335 (1.375 in. Bore), 801336 (1.500 in. Bore), 801337 (1.625 in. Bore) |
Approximate Brake Facing Life |
N/A 1200 hp·hr |
Approximate Engagement Response Time |
N/A 30 ms |
Bore Size |
N/A 0.8750 in1 in1.1250 in1.3750 in1.6250 in1-1/2 in1-1/4 in |
Bore Type |
N/A Straight |
Brake Air Chamber Volume when New |
N/A 78.400 in³ |
Brake Air Chamber Volume when Worn Out |
N/A 16.200 in³ |
Brake Facing Edge Color Code |
N/A Red |
Brake Facing Effective Area |
N/A 17.0 in² |
Brake Facing Type |
N/A Standard Coefficient |
Brake Peak Thermal Input Rate |
N/A 15.00 hp |
Brake Series |
N/A MB |
Engagement |
N/A Spring Engaged |
Release |
N/A Air Release |
Finish |
N/A Bare Cast Aluminum |
Frame Size |
N/A 182T 184T 213 213T 215 215T 254 254U 256T 256U |
Frame Type |
N/A National Electrical Manufacturers Association (NEMA) |
Function |
N/A Stopping and Holding |
Maximum Speed |
N/A 3600 rpm |
Maximum Brake Continuous Thermal Dissipation |
N/A 0.33 hp |
Maximum Pressure |
N/A 80 psi |
Minimum Release Pressure |
N/A 65 psi |
Minimum Static Brake Torque |
N/A 1100 in·lb |
Mounting Configuration |
N/A Flange Mounted |
Open or Enclosed Design |
N/A Enclosed |
Port Size |
N/A 1/8 in |
Port Type |
N/A National Pipe Thread (NPT) |
Rating |
N/A European Conformity (CE) Restriction of Hazardous Substances (RoHS) |
Rebuild Kits |
N/A 801351 |
Recommended Control Kits |
N/A 940012 (3-Way Normally Closed (N.C.) 1/8 in. National Pipe Thread (NPT)) 940017 (3-Way Normally Closed (N.C.) 0 to 100 PSI 1/8 in. National Pipe Thread (NPT)) 940021 (3-Way 5 to 100 psi 1/8 in. National Pipe Thread (NPT)) |
Shaft Inertia |
N/A 12960.00 lb/in² |
Static Torque Capacity |
N/A Up to 1800 lb·ft |
Weight |
N/A 26.50 lb |
Thermal Capacity |
N/A Up to 0.450 hp |
