Supplier Name |
N/A Nexen |
Manufacturer Part Number |
N/A 801990 |
Model Number |
N/A FMBS-1625 |
Approximate Brake Facing Life |
N/A 554 hp·hr |
Approximate Engagement Response Time |
N/A 30 ms |
Bore Size |
N/A 1.6250 in |
Bore Type |
N/A Straight |
Brake Facing Edge Color Code |
N/A Purple |
Brake Facing Effective Area |
N/A 28.9 in² |
Brake Facing Type |
N/A High Coefficient |
Brake Heat Sink Capacity |
N/A 125000 ft·lb |
Brake Peak Thermal Input Rate |
N/A 28.00 hp |
Brake Series |
N/A FMBS |
Engagement |
N/A Spring Engaged |
Release |
N/A Air Release |
Facing Kit |
N/A 801991 |
Finish |
N/A Black Oxide |
Frame Size |
N/A 254TC 256TC |
Frame Type |
N/A National Electrical Manufacturers Association (NEMA) |
Function |
N/A Stopping and Holding |
Maximum Speed |
N/A 1800 rpm |
Maximum Brake Continuous Thermal Dissipation |
N/A 2.23 hp |
Maximum Pressure |
N/A 120 psi |
Maximum Static Brake Torque |
N/A 2160 in·lb |
Minimum Release Pressure |
N/A 90 psi |
Minimum Static Brake Torque |
N/A 1800 in·lb |
Mounting Configuration |
N/A Flange Mounted |
Open or Enclosed Design |
N/A Open |
Port Size |
N/A 1/8 in |
Port Type |
N/A National Pipe Thread (NPT) |
Rating |
N/A European Conformity (CE) National Electrical Manufacturers Association (NEMA) 1.26.55 (Waterproof Machines) Restriction of Hazardous Substances (RoHS) |
Rebuild Kits |
N/A 801992 |
Recommended Control Kits |
N/A 940012 (3-Way Normally Closed (N.C.) 1/8 in. National Pipe Thread (NPT)) 940017 (3-Way Normally Closed (N.C.) 0 to 100 PSI 1/8 in. National Pipe Thread (NPT)) 940021 (3-Way 5 to 100 psi 1/8 in. National Pipe Thread (NPT)) |
Temperature Range |
N/A 40 to 220 ºF |
