Supplier Name |
N/A Nexen |
Manufacturer Part Number |
N/A 824303 |
Approximate Brake Facing Life |
N/A 3066 hp·hr |
Bore Style |
N/A Quick-Detach (QD) Type E |
Bore Type |
N/A Straight |
Brake Air Chamber Volume when New |
N/A 1.847 in³ |
Brake Air Chamber Volume when Worn Out |
N/A 10.707 in³ |
Brake Facing Edge Color Code |
N/A Red |
Brake Facing Type |
N/A Standard Coefficient |
Brake Heat Sink Capacity |
N/A 200000 ft·lb |
Brake Peak Thermal Input Rate |
N/A 45.00 hp |
Engagement |
N/A Air Engaged |
Release |
N/A Spring Release |
Finish |
N/A Black Oxide |
UPC Code |
N/A 662284252409 |
Maximum Speed |
N/A 1800 rpm |
Maximum Brake Continuous Thermal Dissipation |
N/A 3.00 hp |
Maximum Pressure |
N/A 80 psi |
Maximum Static Brake Torque |
N/A 3450 in·lb |
Minimum Engagement Pressure |
N/A 3 psi |
Open or Enclosed Design |
N/A Open |
Outside Diameter |
N/A 11.88 in |
Overall Length |
N/A 4.44 in |
Port Size |
N/A 1/4 in |
Port Type |
N/A National Pipe Thread (NPT) |
Shaft Inertia |
N/A 282.24 lb/in² |
Temperature Range |
N/A 32 to 150 ºF |
Weight |
N/A 47.00 lb |
