  • PCI Procal Inc. CP Series Take-Up Frames
1 - 25 of 90 | Results Per Page | View | Unit of Measure
1 2 3 4
Request Information Compare Items Add to CAD Cart

Item #

Item Name

Bolt Center-to-Center Length

Overall Height

Overall Length

Travel

N/A PCI Procal Inc. CP Series 28.0000 Inch (in) Overall Length Take-Up Frame N/A 26.0000 in N/A 7.0000 in N/A 28.0000 in N/A 12.0000 in
N/A PCI Procal Inc. CP Series 34.0000 Inch (in) Overall Length Take-Up Frame N/A 32.0000 in N/A 7.0000 in N/A 34.0000 in N/A 18.0000 in
N/A PCI Procal Inc. CP Series 40.0000 Inch (in) Overall Length Take-Up Frame N/A 38.0000 in N/A 7.0000 in N/A 40.0000 in N/A 24.0000 in
N/A PCI Procal Inc. CP Series 46.0000 Inch (in) Overall Length Take-Up Frame N/A 44.0000 in N/A 7.0000 in N/A 46.0000 in N/A 30.0000 in
N/A PCI Procal Inc. CP Series 52.0000 Inch (in) Overall Length Take-Up Frame N/A 50.0000 in N/A 7.0000 in N/A 52.0000 in N/A 36.0000 in
N/A PCI Procal Inc. CP Series 29.5000 Inch (in) Overall Length Take-Up Frame N/A 27.5000 in N/A 8.6250 in N/A 29.5000 in N/A 12.0000 in
N/A PCI Procal Inc. CP Series 35.5000 Inch (in) Overall Length Take-Up Frame N/A 33.5000 in N/A 8.6250 in N/A 35.5000 in N/A 18.0000 in
N/A PCI Procal Inc. CP Series 41.5000 Inch (in) Overall Length Take-Up Frame N/A 39.5000 in N/A 8.6250 in N/A 41.5000 in N/A 24.0000 in
N/A PCI Procal Inc. CP Series 47.5000 Inch (in) Overall Length Take-Up Frame N/A 45.5000 in N/A 8.6250 in N/A 47.5000 in N/A 30.0000 in
N/A PCI Procal Inc. CP Series 53.5000 Inch (in) Overall Length Take-Up Frame N/A 51.5000 in N/A 8.6250 in N/A 53.5000 in N/A 36.0000 in
N/A PCI Procal Inc. CP Series 29.5000 Inch (in) Overall Length Take-Up Frame N/A 27.5000 in N/A 9.2500 in N/A 29.5000 in N/A 12.0000 in
N/A PCI Procal Inc. CP Series 35.5000 Inch (in) Overall Length Take-Up Frame N/A 33.5000 in N/A 9.2500 in N/A 35.5000 in N/A 18.0000 in
N/A PCI Procal Inc. CP Series 41.5000 Inch (in) Overall Length Take-Up Frame N/A 39.5000 in N/A 9.2500 in N/A 41.5000 in N/A 24.0000 in
N/A PCI Procal Inc. CP Series 47.5000 Inch (in) Overall Length Take-Up Frame N/A 45.5000 in N/A 9.2500 in N/A 47.5000 in N/A 30.0000 in
N/A PCI Procal Inc. CP Series 53.5000 Inch (in) Overall Length Take-Up Frame N/A 51.5000 in N/A 9.2500 in N/A 53.5000 in N/A 36.0000 in
N/A PCI Procal Inc. CP Series 30.5000 Inch (in) Overall Length Take-Up Frame N/A 28.5000 in N/A 9.5000 in N/A 30.500 in N/A 12.0000 in
N/A PCI Procal Inc. CP Series 36.5000 Inch (in) Overall Length Take-Up Frame N/A 34.5000 in N/A 9.5000 in N/A 36.5000 in N/A 18.0000 in
N/A PCI Procal Inc. CP Series 42.5000 Inch (in) Overall Length Take-Up Frame N/A 40.5000 in N/A 9.5000 in N/A 42.5000 in N/A 24.0000 in
N/A PCI Procal Inc. CP Series 48.5000 Inch (in) Overall Length Take-Up Frame N/A 46.5000 in N/A 9.5000 in N/A 48.5000 in N/A 30.0000 in
N/A PCI Procal Inc. CP Series 54.2000 Inch (in) Overall Length Take-Up Frame N/A 52.5000 in N/A 9.5000 in N/A 54.2000 in N/A 36.0000 in
N/A PCI Procal Inc. CP Series 32.5000 Inch (in) Overall Length Take-Up Frame N/A 30.5000 in N/A 11.1563 in N/A 32.5000 in N/A 12.0000 in
N/A PCI Procal Inc. CP Series 38.5000 Inch (in) Overall Length Take-Up Frame N/A 36.5000 in N/A 11.1563 in N/A 38.5000 in N/A 18.0000 in
N/A PCI Procal Inc. CP Series 44.5000 Inch (in) Overall Length Take-Up Frame N/A 42.5000 in N/A 11.1563 in N/A 44.500 in N/A 24.0000 in
N/A PCI Procal Inc. CP Series 50.5000 Inch (in) Overall Length Take-Up Frame N/A 48.5000 in N/A 11.1563 in N/A 50.5000 in N/A 30.0000 in
N/A PCI Procal Inc. CP Series 56.5000 Inch (in) Overall Length Take-Up Frame N/A 54.5000 in N/A 11.1563 in N/A 56.5000 in N/A 36.0000 in
